Luxpower SNA-EU 12K / 14K High-Capacity Hybrid Inverter – 24kW PV, 250A, Off-Grid, Generator & Smart Load Support(PV/Grid/Battery/GEN)

🔋 SNA-EU 12K / 14K Hybrid Off-Grid Inverter

Powerful. Flexible. Ready for Anything.

Designed for homes, businesses, and industrial-grade energy independence, the SNA-EU 12K / 14K Hybrid Inverter from Lux Power Technology delivers an all-in-one solution that combines solar, battery, grid, and generator power in a smart, scalable, and reliable package.

Whether you are building an off-grid system, enhancing energy security in a loadshedding region, or integrating with existing solar arrays, the SNA-EU series is your go-to power control center.

🌞 Key Features at a Glance

• 🔹 Max PV Input Power: Up to 24,000W (2 MPPTs)

• 🔹 Max Battery Charge/Discharge Current: 250A

• 🔹 Rated Output Power: 12kW / 14kW (Single-phase)

• 🔹 Max Generator/AC Coupling Input: 19.2kW

• 🔹 Parallel Function: Connect up to 16 units (single-phase or 3-phase systems)

• 🔹 Dual AC Outputs: Separate loads with EPS backup and smart load control

• 🔹 Battery Compatibility: 48V Lithium-ion and Lead-acid

• 🔹 PV & AC Charging Support: For flexible power management

• 🔹 Communication: RS485, CAN, WiFi/4G dongle, remote monitoring

• 🔹 Integrated Battery & Load Breakers

• 🔹 Protection: Full range of surge, polarity, voltage, and overload protection

⚙️ Technical Specifications

🧠 Advanced Energy Management Modes

• Self-Consumption: Use solar first, then battery, then grid.

• Charge-First Mode: Prioritize charging battery from solar or AC before powering loads.

• Time-Based Force Modes: Set schedules for charging/discharging to match TOU tariffs or loadshedding.

• Bypass Mode: Grid directly powers loads while solar charges battery.

• Off-Grid Mode: Fully independent power with load and battery priority.

• Hybrid Mode: Solar + AC jointly support loads.

🔌 Smart Load & Generator Integration

• Smart Load Output: Automatically powers water heaters, EV chargers, or other heavy appliances only when solar/battery are sufficient.

• Generator Support:

  • Up to 19.2kW input

  • Auto start/stop via dry contact

  • Charge battery and support loads during outages

• AC Coupling Ready: Retrofit-friendly with on-grid inverters, allows export control and solar backup continuity.

📱 Remote Monitoring & Control

• Connect via WiFi, GPRS or 4G dongles

• Free mobile app (iOS & Android) and web platform: server.luxpowertek.com

• Real-time data: Solar production, battery status, load profile, grid export/import

• Remote firmware updates and multi-inverter management

🛡️ Built for Reliability

• Overload, surge, reverse polarity, and short-circuit protections

• Transformer-less topology with high power density

• Built-in smart cooling system (quiet, <50 dB)

• CE Certified, 2-year warranty (extendable)

🏘️ Ideal Applications

• 🏡 Residential: Solar + Battery + Generator systems for full autonomy

• 🏢 Commercial & Retail: Smart load separation, peak shaving, and backup

• 🏭 Industrial Sites: Supports heavy loads with 250A surge

• 🏕️ Remote or Rural: Full off-grid or microgrid applications

💡 Why Choose SNA-EU 12/14K?

✅ Handles high PV power and heavy loads
✅ Flexible use with or without batteries
✅ Advanced hybrid and off-grid modes
✅ Seamless integration with generators and existing inverters
✅ Expandable up to 192kW total output in parallel setups
✅ Smart, safe, and easy to monitor

🔗 Learn more at: www.luxpowertek.com
📞 Contact us for distributor pricing, installation guides, and tech support

SNA-12-14K-Datasheet

Download

SNA-12-14K-User-Manual

Download
