Deye SUN-5K-SG04LP1-EU-SM2 | 5kW Single Phase Hybrid Inverter | 120A Battery Support | IP65 | Dual MPPT | On/Off-Grid Compatible

The Deye SUN-5K-SG04LP1-EU-SM2 is a high-performance 5kW single-phase hybrid inverter designed for residential and small commercial applications that require seamless integration of solar power, battery storage, and backup energy capabilities. Compact yet powerful, it supports flexible on-grid and off-grid operation, allowing homeowners to take full control of their energy independence and optimize solar self-consumption.

⚙️ All-in-One Energy Control

With a rated output of 5000W and peak power capability of 10kW for 10 seconds, the SUN-5K inverter is perfect for managing essential household loads during outages or grid instability. It supports lead-acid and lithium-ion batteries with up to 120A charging/discharging current, ensuring fast energy storage and delivery when needed.

Thanks to adaptive BMS compatibility, the inverter automatically communicates with most lithium battery brands, providing safe and intelligent charge cycles.

☀️ Advanced Solar Power Integration

Built with dual MPPT trackers and wide PV voltage input, the inverter offers:

• Max PV Input Power: 9600W

• MPPT Voltage Range: 150–425V

• Max PV Voltage: 500V

• Dual MPPT with 2 strings for optimal energy harvesting

This ensures maximum energy capture even under partial shading or different roof orientations.

🔋 Battery Support & Parallel Operation

• Battery Voltage Range: 40V–60V

• Max Charging/Discharging Current: 120A

• Battery Types: Lithium-ion or Lead-acid

• Supports up to 16 units in parallel, ideal for expanding into larger or three-phase systems

• Compatible with diesel generators, perfect for remote or off-grid sites

📶 Smart Features & Remote Monitoring

• 6 customizable time slots for battery charging/discharging

• Colorful touch LCD screen for local control

• Supports WiFi, GPRS, 4G, Bluetooth, or LAN for remote monitoring (optional)

• Integrated RS485, RS232, and CAN communication interfaces for full system integration

🛡️ Built to Last & Protect

• Max Efficiency: 97.6%, Euro Efficiency: 96.5%

• THDi < 3% for grid compliance

• IP65-rated housing for outdoor installation

• Ultra-quiet natural cooling system (no fan)

• Full protection suite: short circuit, overvoltage, overtemperature, reverse polarity, ground fault, DC insulation monitoring

• Surge protection: Type II for AC and DC

• Compliant with IEC 61727, IEC 62116, NRS 097, VDE-AR-N 4105, EN 50549, and more

📦 Quick Product Summary

The Deye SUN-5K-SG04LP1-EU-SM2 offers an unbeatable combination of performance, scalability, and smart energy management. Whether you’re designing a resilient backup system, maximizing self-consumption, or preparing for energy independence, this inverter delivers clean, reliable power—today and for years to come.
