LUMO LMCB280 HV Control Box – Advanced Control and Protection for High-Voltage Systems
Original price was: R28,500.00.R23,500.00Current price is: R23,500.00.
Ensure maximum efficiency and security with the LUMO LMCB200 HV Control Box. Designed for high-voltage systems, it provides advanced protection and seamless integration with LUMO HV batteries and inverters. Protect your energy infrastructure today!
Precision Control for High-Voltage Applications
The LUMO LMCB200 HV Control Box is engineered to provide exceptional control and protection for high-voltage systems. Whether you’re using LUMO HV batteries in a commercial or industrial application, this control box ensures your energy setup operates efficiently and safely. With overcurrent protection, temperature regulation, and overvoltage safeguards, the LMCB200 guarantees that your high-voltage energy infrastructure remains secure and operational at all times, preventing potential damage to components and ensuring uninterrupted power.
Seamless Integration for Optimized Performance
Designed to integrate effortlessly with LUMO HV batteries and inverters, the LUMO LMCB200 HV Control Box ensures smooth operation and maximum efficiency for your energy storage system. It optimizes communication between components, enabling fast, reliable energy flow between your batteries, inverters, and the grid. With its easy installation and user-friendly interface, you can confidently monitor and adjust system settings, making it the perfect solution for businesses seeking to optimize energy management in high-demand environments.
Superior Protection for Long-Term Durability
The LUMO LMCB200 HV Control Box is designed with durability and longevity in mind. Built to withstand the rigors of industrial and commercial environments, it ensures the long-term protection of your high-voltage energy system. The box’s smart Battery Management System (BMS) helps to maintain optimal charging and discharging cycles for your batteries, enhancing their lifespan and overall energy efficiency. It also provides peace of mind with advanced fault detection and real-time diagnostics, ensuring your system remains in top condition year after year.
| Item | Basic Parameters | |
| Related Product | 1000V 140A | |
| 1 | AC supply | — |
| 2 | System Operation Voltage (Vdc) | 0-1000V |
| 3 | Nominal Current(A) | 140 |
| 4 | Self-consumption Power(W) | 8 |
| 5 | Dimension (W* D* H, mm) | 483*460*177 |
| 6 | Communication | RS485/CAN |
| 7 | Protection Class | IP20 |
| 8 | Weight(KGS) | 20 |
| 9 | Operation Life | 10+ |
| 10 | Operation Temperature | -20~65 |
| 12 | Storage Temperature | -40~80 |
| Weight | 20 kg |
|---|---|
| Dimensions | 48.3 × 46 × 17.7 cm |
