The Deye SUN-OG01LP1-EU-AM2 Series Eco Hybrid Inverters offer a powerful, flexible, and intelligent energy solution tailored for modern off-grid solar systems. Designed with scalability and real-world efficiency in mind, this new generation of Deye inverters supports both lithium-ion and lead-acid battery technologies while delivering seamless solar, battery, and generator integration.
Ideal for residential homes, small businesses, rural installations, and backup power systems, the SUN-3K to 6K models enable optimized energy independence with impressive PV input capacity, robust charging capabilities, and a full suite of smart protections.
Key Features & Benefits
✅ Wide PV & Battery Compatibility
• Supports lithium-ion and lead-acid batteries
• Self-adaptive BMS communication (for lithium batteries)
• Battery voltage range: 20–30V (3K model) / 40–60V (3.6K–6K)
✅ High PV Input Capacity & Dual MPPT
• Oversized PV input for maximum solar harvesting (up to 12,000W)
• Dual MPPT trackers for precise energy optimization (from 5K model and up)
• Wide MPPT range: 150–425V, optimal operation at 300–425V
✅ Robust AC Power Output
• Pure sine wave AC output at 230V ±2%
• Peak power support: 2x rated output for 10 seconds – ideal for motor loads
• Total harmonic distortion (THDi) <3% for clean power
✅ Efficient Grid/Generator Charging
• Max charging/discharging current up to 135A
• Supports generator input up to 35A
• Fast and intelligent battery recharging options
✅ Smart Monitoring & Connectivity
• Built-in LCD display
• WiFi, RS485, CAN, and Bluetooth communication
• Compatible with external BMS, smart meters, and remote management
✅ Rugged & Reliable Design
• IP65-rated weatherproof enclosure
• Quiet operation (<55 dB)
• Intelligent air cooling, 3000m max altitude, -40°C to +60°C operating range
• Built-in protections: reverse polarity, overcurrent, short circuit, surge (Type II), ground fault, insulation monitoring, arc fault interrupter (optional)
Model Comparison Table
| Feature | SUN-3K | SUN-3.6K | SUN-5K | SUN-6K |
|---|---|---|---|---|
| Rated AC Output Power (W) | 3000 | 3600 | 5000 | 6000 |
| Max. PV Access Power (W) | 6000 | 7200 | 10000 | 12000 |
| Max. PV Input Power (W) | 4800 | 5760 | 8000 | 9600 |
| No. of MPPT Trackers | 1 | 1 | 2 (1+1) | 2 (1+1) |
| Battery Voltage Range (V) | 20–30 | 40–60 | 40–60 | 40–60 |
| Max Charging Current (A) | 130 | 90 | 120 | 135 |
| Max Discharging Current (A) | 130 | 90 | 120 | 135 |
| Max Efficiency | 97.6% | 97.6% | 97.6% | 97.6% |
| MPPT Efficiency | >99% | >99% | >99% | >99% |
| Max AC Output Current (A) | 13.1 | 15.7 | 21.8 | 26.1 |
| Max Generator/Grid Input (A) | 35 | 35 | 35 | 35 |
| Surge Protection Level | Type II (AC & DC) | Type II (AC & DC) | Type II (AC & DC) | Type II (AC & DC) |
| Weight (kg) | 12.65 | 12.65 | 12.65 | 12.65 |
Applications
-
Off-grid homes and cottages
-
Agricultural and farming systems
-
Remote telecom base stations
-
Disaster recovery and backup systems
-
Commercial buildings seeking energy independence
Warranty & Certification
• Standard 5-year warranty, extendable upon request
• Certified to IEC62109-1/2, EN61000-6 series standards
• Meets global safety and EMC compliance requirements
Ready to Take Control of Your Energy?
The Deye SUN-OG01LP1-EU-AM2 Eco Hybrid Inverter is a premium choice for modern solar systems seeking performance, reliability, and smart off-grid power. Whether you’re building a new installation or upgrading an old one, this inverter series brings intelligent solar energy to your fingertips.
